SEW0063-29404CLV3 SLIM AC CLAMP METER ACV750 DCV1000 ACA1000
● Pocket size.
● 4000 counts.
● Full automatic measurement.
Voltage measurement.
Current measurement.
Resistor measurement.
● Data hold function.
● Continuity check.
● Diode measurement.
● Select function.
● Low battery indication.
● Auto off function.
● Flashlight (Auto off in 1 minute).
AC A |
||
Ranges |
Resolution |
Accuracy |
400.0A |
0.1A |
±(2.0%rdg+5dgt) |
1000A |
1A |
|
AC V |
||
Ranges |
Resolution |
Accuracy |
4.000V |
1mV |
±(1.5%rdg+10mV) |
40.00V |
10mV |
±(1.5%rdg+5dgt) |
400.0V |
100mV |
|
750V |
1V |
|
DC V |
||
Ranges |
Resolution |
Accuracy |
4.000V |
1mV |
±(1.0%rdg+5dgt) |
40.00V |
10mV |
|
400.0V |
100mV |
|
1000V |
1V |
|
Resistance |
||
Ranges |
Resolution |
Accuracy |
400.0Ω |
0.1Ω |
±(1.5%rdg+3dgt) |
4.000kΩ |
1Ω |
|
40.00kΩ |
10Ω |
|
400.0kΩ |
100Ω |
|
4.000MΩ |
1kΩ |
|
40.00MΩ |
10kΩ |
±(2.0%rdg+4dgt) |
Continuity |
||
Ranges |
Audible threshold |
|
400.0Ω |
Less than 25Ω |
|
GENERAL |
||
Overload Protection |
AC V : 750Vrms |
|
Conductor size |
35mm Max. |
|
Low battery indication |
http://www.sew.com.tw/ezfiles/sew1/img/img/174697/-+.png" height="19" width="32"> Sign appears on the display |
|
Response time |
Approx. 2 times per second |
|
Operating temperature |
0ºC ~ 40ºC |
|
Storage temperature |
0ºC to 50ºC |
|
Battery life |
Approx.100 hours on continuous use |
|
Dimensions |
183(L) × 62(W) × 20(D)mm |
|
Weight |
Approx. 105g |
|
Power source |
CR 2032 (DC 3V) × 1 |
|
Safety standard |
EN 61010-1 CAT II 600V |
